The BMW 117 was a piston aircraft engine developed by BMW in the 1930s. Development work stopped in 1937. The BMW 117 engine was initially known as the BMW XV.
Specifications (BMW 117)
General characteristics
- Type: V-12
- Bore: 155.6 mm (6.13 in)
- Stroke: 158 mm (6.22 in)
- Displacement: 36 L (2,196.85 cu in)
- Length: 1,809 mm (71.22 in)
- Width: 740 mm (29.1 in)
- Height: 985 mm (38.8 in)
- Dry weight: 525 kg (1,157 lb)
Components
- Supercharger: radial supercharger
- Fuel system: injection
- Cooling system: Liquid cooled
Performance
- Power output: 905 hp (675 kW) at 2320 rpm
- Compression ratio: 6.5:1
